PROC IMPORT is the SAS procedure used to read data from excel into SAS. This tutorial covers how to import excel data to SAS with PROC IMPORT. Loading excel data to SAS is one of the most common task of a SAS programmer / analyst. Most of the raw data files are saved in MS Excel so we need to take it to SAS for further analysis.
SAS : PROC IMPORT Excel

PROC IMPORT Syntax:


1. DATAFILE= option tells SAS where to find the Excel file that you want to import
(Complete filename path).

For example : DATAFILE = "C:\Desktop\age.xls"

2. OUT= option tells SAS to create a dataset with any name of your choice. By default, the imported dataset is saved on WORK library (temporary library)

 Examples :

i. OUT = Age
In this statement, PROC IMPORT uses the WORK library. This implies OUT = Age is equivalent to OUT = Work.Age .

ii. OUT = Input.Age.
In this statement, PROC IMPORT uses the Input library (Permanent library).

3. DBMS= option tells SAS the type of file to read.

 Examples :

i. DBMS =  XLS for Excel 97-2003 workbooks
ii.DBMS =  XLSX for Excel 2007 - 2013 workbooks

4. REPLACE is used to overwrite the existing SAS dataset (If any) mentioned in the OUT= option.

5. SHEET= option is used to specify which sheet SAS would import.

 Examples :

i.  SHEET =  "Sheet1" - To import data from worksheet named sheet1.
ii. SHEET =  "Goal" - To import data from worksheet named Goal.


6. GETNAMES= YES tells SAS to use the first row of data as variable names.

By default, PROC IMPORT uses GETNAMES= YES. If you type GETNAMES= NO, SAS would not read variable names from first row of the sheet.

7. DATAROW= option is used to specify starting row from where SAS would import the data.

For example : DATAROW =5 tells SAS to start reading data from row number 5.

Note :

i. When GETNAMES=YES, DATAROW must be greater than or equal to 2.
ii. When GETNAMES=NO, DATAROW must be greater than or equal to 1

8. RANGE= option is used to specify which range SAS would import.

Examples :

i. RANGE="Sheet1$B2:D10"
 This would tell SAS to import data from range B2:D10 from sheet1

ii. RANGE="Information"
 This would tell SAS to import data from excel defined name range. In the example shown above, it is Information.


Importing an XLS (MS Excel 97-2003) format file into SAS


  1. DATAFILE= "C:\age.xls" tells SAS where to find the Excel file that you want to import.
  2. OUT= WORK.age tells SAS to create a dataset named age stored in WORK library
  3. DBMS= XLS tells SAS the XLS (Excel 97-2003) format file to read.
  4. REPLACE is used to overwrite the age dataset if it exists already.
  5. SHEET= "Sheet1" tells SAS to import data from Sheet1.
  6. GETNAMES="YES" tells SAS to use the first row of data as variable names.

Importing an XLSX (MS Excel 2007-2013) format file into SAS



DBMS=XLSX tells SAS the XLSX (Excel 2007-2013) format file to read.

Important Note -
Earlier SAS Versions before SAS9.2 does not support XLSX formatted file (Excel 2007 or later files). If your XLSX file contains records fewer than 65000 rows and 255 columns, you can save the file in XLS format by clicking on SAVE AS >> Excel 97-2003 Workbook. Later you can import the converted XLS file into SAS.

Importing an excel file from specified row



DATAROW=5 tells SAS to start reading data from row number 5. In this case, variable (column) names would be pulled from first row but column values would be extracted from row 5.

Importing variable name from other than first row

Suppose variable names are placed at second row in excel sheet.
PROC IMPORT DATAFILE= "E:\SAS Code Repository\Book1.xlsx"
 DBMS=XLSX
 OUT= TEMP  REPLACE;
 NAMEROW=2;
 STARTROW=3; GETNAMES=YES;
RUN;
NAMEROW=2 tells SAS to extract variable names from second row and STARTROW=3 is used to pull values from third row.

Importing only specified columns from excel file



The OUT = filename followed by KEEP=  statement is used to retain the desired variables. In the example shown above, we retained four variables ID,X,Y and Z.

In the same way, you can use DROP= statement to remove the variables that you don't want to retain.

For example : You don't want to import three variables say A, B and C.
PROC IMPORT OUT= WORK.want (DROP=A B C) DATAFILE= "C:\Desktop\File1.xls" DBMS=XLS REPLACE;     GETNAMES=YES;RUN;
Importing only rows that have non-missing data for all the variables



In the example shown above, WHERE= statement is used to delete all the rows that have only missing data on variables x,y and z.

Importing data from excel using specified range



RANGE="Sheet1$B4:E100" tells SAS to import data from range B4:E100 from sheet1.

Importing data from excel using named range

Range Name: In MS Excel, it is a name that represents a cell, range of cells. You can create your own defined name.

Creating a range name is very simple. Select a cell or range of cells and Click on the Name box above Column A and Tye any name you want and Press Enter.

In the example below, Range A1:C10 is selected and then type Info in the name box and Press Enter.

SAS : Using Excel Named Range


RANGE="Info" tells SAS to import data from excel using user defined named range Info.

Rename columns while Importing

The variable names can be renamed using RENAME= option next to OUT= option.
PROC IMPORT DATAFILE= "E:\SAS Code Repository\Book1.xlsx"
 DBMS=XLSX
 OUT= TEMP (RENAME=(Score=TotalScore))  REPLACE;
 GETNAMES=YES;
RUN;

Importing an excel file from web page into SAS




SAS provides a method for extracting data from web pages - the URL access method of the FILENAME statement.This method makes it easy to read data from web pages. This doesn't work for webpages that ask user to login to get information about the desired data.
